2N3055 NPN Power Transistor
Onsemi, USA
United States
Complementary silicon power transistors are designed for general−purpose switching and amplifier applications.

Features :
• DC Current Gain − hFE = 20−70 @ IC = 4 Adc
• Collector−Emitter Saturation Voltage − VCE(sat) = 1.1 Vdc (Max) @ IC = 4 Adc
• Excellent Safe Operating Area
• Pb−Free Packages are Available*

MAXIMUM RATINGS
Rating Symbo Value Unit
Collector−Emitter Voltage VCEO 60 Vdc
Collector−Emitter Voltage VCER 70 Vdc
Collector−Base Voltage VCB 100 Vdc
Emitter−Base Voltage VEB 7 Vdc
Collector Current − Continuous IC 15 Adc
Base Current IB 7 Adc
Total Power Dissipation @ TC = 25°C Derate Above 25°C PD 115 0.657 W W/°C
Operating and Storage Junction Temperature Range
TJ, Tstg −65 to +200 °C

Maximum ratings are those values beyond which device damage can occur. Maximum ratings applied to the device are individual stress limit values (not normal operating conditions) and are not valid simultaneously. If these limits are exceeded, device functional operation is not implied, damage may occur and reliability may be affected.
